it is mainly used in Military industry, drones, medical minimally invasive aspects
| Technical parameters | ||
| No. | Name | LHSZ240-24 |
| 1 | inlet | φ0.55mm--φ1.2mm |
| 2 | finish | φ0.10mm--φ0.40mm |
| 3 | line speed(max) | 2500m/min (50--100kg Capa city of receiving line) |
| 4 | Maximum mold number | 24（1+11+11+1） |
| 5 | Reduction rate | 15% , final : 14% |
| 6 | Wire drawing mode | Up and down 2,4 groups of pulley,Double mould rack,Spray sliding type |
| 7 | The cone pulley | φ240×11(4 group), Capstan φ150(1 group) Ceramic spray cone pulley |
| 8 | main motor 15KW | <YX3-160M2-2> Three-phase AC |
| 9 | winding motor 5.5KW | <YX3-132S1-2> Three-phase AC |
| 10 | Wire winding motor(servo) | 200W <20B330CB> Single phase AC |
| 11 | water pump motor | 120W cooling pump (Three-phase AC) |
| 12 | wire drawing lighting | 220V 30W |
| 13 | Receiving line lighting | 220V 7W-11W energy-saving light |
| 14 | Electromagnetic Stop device | 24V 30W |
| 15 | speed control mode | Control small electric cabinet panel multi ring position, potentiometer speed regulation |
| 16 | traverse method | Ball screw drive, servo motor positive and negative, maximum width 200mm-280mm |
| 17 | lubricating system | Fan shaped spray type (With water tank, water pump, put the line rack ) |
| 18 | exterior dimensions | LXWXH: 1668×1210×1980mm |
| 19 | full car weight | 2.3T |
| 20 | Reel size of receiving line | Small : φ300×270×φ215×250×φ125 |
| （Steel plate,Dynamic balance requirement G3） | ||
| Big : φ400×304×φ270×280×φ127 | ||
| （Steel plate,Dynamic balance requirement G3） | ||
