QSF45-10 Full servo micro drawing machine

QSF45-10 Full servo micro drawing machine
QSF45-10 Full servo micro drawing machine QSF45-10 Full servo micro drawing machine QSF45-10 Full servo micro drawing machine
Product Attributes :

Inlet:φ0.55mm--φ1.2mm

Outlet :φ0.10mm--φ0.40mm

It is used in Military industry, drones, medical minimally invasive aspects

Product Description

Inlet:φ0.55mm--φ1.2mm

Outlet :φ0.10mm--φ0.40mm

it is used in Military industry, drones, medical minimally invasive aspects

2.Technical parameters
No. Name LHS220-24
1 Incoming blank line φ0.55mm--φ1.2mm
2 Finished product φ0.10mm--φ0.40mm
3 Maximum line speed 2200m/min
4 Maximum number of molds 24
5 Reduction rate 15% at last 14%
6 Lubrication method sector-sprayed style
7 total power 15.5KW/21KW
8 main motor power 15KW/5,5KW
9 line arrangement method synchronous motor silk rod drive
10 take-up bobbin dimension Φ300×270×φ215×250×φ125mm
Φ400×304×φ270×280×φ127mm
11 overall dimension L×W ×H:1620×1565×1995mm
12 weight 2.13 ton
13 max take-up bobbin capacity 50-100kg
14 display mode Color touch sreen PLC control
Note: To achieve this technical specification, it is necessary to ensure the use of high-quality wire and good lubricating fluid and drawing die, and use a reasonable stretching process to fully import electrical control box, digital display working status. The frequency conversion speed control computer automatically controls the processing parameters of each process.
