Inlet φ0.12mm--φ0.55mm
Outlet φ0.030mm--φ0.12mm
it is used in Military industry, drones, medical minimally invasive aspects
|
Technical parameters |
||
| No. | Name | LHS150-24 |
| 1 | Incoming blank line | φ0.12mm--φ0.55mm |
| 2 | Finished product | φ0.030mm--φ0.12mm |
| 3 | Maximum line speed | 2200m/min |
| 4 | Maximum number of molds | 24 |
| 5 | Reduction rate | 11% at last 10% |
| 6 | Lubrication method | sector-sprayed style |
| 7 | total power | 8.2KW |
| 8 | main motor power | 4/4KW |
| 9 | line arrangement method | Optical fiber scanning PLC control,ball screw drive,servo motor forward and reverse rotation |
| 10 | take-up bobbin dimension | Φ200×216×φ160×180×φ80mm(Plastic plate 12kg) |
| Φ300×270×φ215×250×φ125mm(Iron plate 50kg) | ||
| 11 | overall dimension | Length × width × height 1800 × 1090 × 1875mm |
| 12 | weight | 1.27t |
| 13 | max take-up bobbin capacity | 12-50kg |
| 14 | display mode | Color touch sreen PLC control |
