Technical parameter of full line
1.
|
Strength member
|
Φ1mm～Φ10.0mm
|
2.
|
Maximum diameter after SZ
|
Φ20mm
|
3.
|
No. and diameter of loose tube
|
(Φ1.5mm～Φ3.5mm)/12
|
4.
|
Structure speed
|
100m/min
|
5.
|
Production speed(binder pitch:25mm, cabling pitch:65mm)
|
80m/min
|
6.
|
Cabling pitch
|
(50~250)mm
|
7.
|
SZ stranding angle
|
±(4～18)π
|
8.
|
SZ rotation speed
|
Max 2000 rpm
|
9.
|
Binder rotation speed
|
Max 4000 rpm
|
10.
|
Binder pitch
|
15~50mm
|
11.
|
Precision of meter-counter
|
≤0.2％
|
12.
|
Additional loose after production
|
≤0.02dB/km
|
13.
|
Machine color and direction
|
It’s up to customer
|
14.
|
Machine power source
|
380V 50HZ three phase five wire
|
15.
|
Machine power
|
48KVA
|
16
|
Line length
|
42m
|
17
|
Weight
|
14 ton
|
Main equipment part
|
1.
|
800-1250mm single-head steel wire reinforcing core magnetic powder pay-off
|
1set
|
|
2.
|
Φ800mm double wheeled magnetic powder tension device
|
1set
|
|
3.
|
Φ800mm loose tube motorized pay off
|
12 sets
|
|
4.
|
SZ oscillator
|
1set
|
|
5.
|
Double heads binder
|
1set
|
|
6.
|
Double heads water blocking tape pay off
|
1set
|
|
7.
|
Single head binder
|
1set
|
|
8.
|
800mm double wheel capstan
|
1set
|
|
9.
|
Swing type take-up tension dance wheel device and guide-wheel fixed frame
|
1set
|
|
10.
|
Traversing unit
|
1set
|
|
11.
|
Φ800~1600mm shaft less take up machine
|
1set
|
|
12.
|
Main control cabinet(IPC+PLC control)
|
1set
|
1.Who are we?
Hooha company Limited is based in Hongkong, china.Factory is located in dongguan,China.Established in 2003, with 19 years of experience in wire and cable field trade.It only takes 1 hour from our company to guangzhou/shenzhen airport.
2.How can we guarantee quality?
1.Online inspect facotry,production,shipment,and aftersales services.
2.pre-production sample before mass production.
3.Highstandards and strict requirements, key accessories of cable equipment only use imported parts.
4.Mechnical parts gurantee 12months, elcctrical parts 12 months.
5.online communication,remote assistance,solve customer problem 24 hours,when the problem can not solved online,we will dispatch engineer to go aboard to the problem on-site for the customer.
3.What can you buy from us?
1.material for wire and cable
2.turkey project for wire and cable
3.extrusion line/bunching/twisting
machine for wire and cable
4.accessorries for cable equipments
4.How long is your delivery time?
1.Generally, 3-7 days for goods in stock
2.30 days for goods after realsing order.
3.project will take 60-90 days
5. Will the price be cheaper if the order is placed in bulk?
Yes,Of course,it will make 10%-12% discount
6.What services can we provide?
1.Plant solution and machine design.
2.technical support at machines and cable
3.Installtion and commmsioning,after sales service.
4.Packaging customization 5.Customized,saving 10%-20% year-on-year cost
7.HOOHA cable equipment technical advantages
1.In order to ensure the high quality of products,we start from ensuring the accuracy of accessories, and the main accessories of products(Casing, end cover, shaft and wheel) they are all manufactured by CNC machining center,The main purchased parts are NSK Bearings from Japan,American gates belt,taiwan TTO Fluoro rubber oil seal,The working efficiency of the equipment is improved, the noise is reduced, and the service life of the equipment is extended to more than 10 years.
2.High precision dynamic balancing of all equipment rotors,The dynamic balance level is G1, reducing the unbalance to less than 1G, and the long-term operation is safe and reliable.
3.The bearing adopts double row cylindrical roller bearing and double row self-aligning roller bearing,compared with
the deep groove ball bearing, the bearing has high fatigue strength, long service life, stable operation and small vibration.
